Product Overview
260W High-Power 915nm Direct-Beam Laser System with Integrated Battery and Protective Carrying Case
The 260W Integrated Laser System combines a compact all-in-one structure, direct-beam optical output, coaxial green aiming laser, rechargeable lithium battery, and protective carrying case into a portable solution for professional optical testing, laboratory demonstrations, equipment evaluation, and authorized industrial applications.
Designed around a high-power laser module, the system features an integrated battery design, eliminating external power cables while maintaining convenient portability. The included hard carrying case provides reliable protection during storage and transportation.
Key Features
Powerful 260W Optical Performance
Built for demanding optical applications, this system delivers up to 260W of optical power with a stable direct-beam output. Its concentrated beam profile is suitable for laboratory research, optical alignment, and controlled technical demonstrations.
Compact Integrated Construction
Unlike split-type systems, the laser module, battery pack, power management, and control circuitry are housed in a single enclosure.
This integrated design offers:
- Fast setup with minimal connections
- Improved portability
- Reduced cable management
- Easier transport between work locations
Convenient storage in the included carrying case
Precision Coaxial Green Alignment
The built-in green aiming laser shares the same optical axis as the primary laser beam, allowing quick and intuitive alignment before operation.
The coaxial configuration helps maintain consistent positioning over varying working distances and simplifies beam adjustment during setup.
Straight-Beam Optical Output
Engineered with a direct-output optical architecture, the system produces a focused straight beam without requiring an external fiber delivery system, resulting in a compact and efficient design.
High-Capacity Rechargeable Power System
The integrated battery pack uses 8 high-performance lithium-ion cells to provide reliable power for field and laboratory use.
- Battery Voltage (Fully Charged): 33.6V
- Maximum Output Power: 528W
The onboard battery system eliminates external power cables while maintaining dependable energy delivery throughout operation.
Intelligent Temperature Management
To enhance operational safety and protect internal components, the laser incorporates an automatic temperature monitoring system.
When the internal temperature approaches 45°C, the protection circuit temporarily interrupts output until the unit cools to a safe operating range.
At approximately 20–25°C ambient temperature, a fully cooled unit typically operates for around 40 seconds before thermal protection may activate. Actual operating time depends on environmental conditions, ventilation, duty cycle, and system temperature.
Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Integrated High-Power Laser System |
| Optical Output Power | 260W |
| Main Wavelength | 915nm |
| Output Type | Direct beam / straight beam |
| Auxiliary Aiming Light | Coaxial green laser |
| Battery | 8-cell rechargeable lithium battery |
| Fully Charged Voltage | 33.6V |
| Maximum Battery Output | 528W |
| Thermal Protection | Automatic activation at approximately 45°C |
| Cold-Start Runtime | Approximately 40 seconds at room temperature |
| Net Weight | Approximately 2.42kg |
| Weight with Carrying Case | Approximately 4.4kg |
| Carrying Case Size | 400 × 280 × 140 mm |
| Shipping Package Size | 415 × 315 × 155 mm |
Portable Protective Carrying Case
The included hard carrying case is designed for convenient transportation and storage.
Benefits include:
- Impact-resistant protection
- Organized equipment storage
- Easy transportation
- Suitable for field work and laboratory use
- Improved equipment protection during shipping
Recommended Applications
- Optical system testing
- Laboratory demonstrations
- Beam alignment
- Material-response evaluation
- Optical research
- Industrial equipment testing
- Professional engineering projects
- Research and development
This product is intended for professional and authorized applications only.
Safety Information
This is a high-power laser product intended for trained operators in controlled environments.
- Never direct the beam toward people or animals.
- Never point the laser at aircraft, vehicles, public roads, or reflective surfaces.
- Wear certified laser safety eyewear suitable for the operating wavelength.
- Operate only in controlled environments with appropriate beam containment.
- Keep the device away from children and unauthorized users.
- Follow all applicable local regulations regarding ownership, transportation, and operation.
