Specification
| Output power：500~1600 W Wavelength：755/808/1064 nm Bar quantity ：24 Pcs Light size：Can be Customized according to customers mm X mm Working current ：50-100 A Working voltage：1.8V/Bar V Duty cycle：≤40 % Pulse width：≤400 msec Frequency：1~10 Hz Water quality ：Distilled or deionized water Water temperature ：18~30 ℃ Water pressure：0.3~0.4 Mpa Water discharge：3.0~4.0 lpm |
Product Description
1.Gold tin packaging.
2.High reliability and stability.
3.Standard industrial structure.
4.Can be customized with crystal size.
5.Good homogenization and low light loss.
6.Can be customized according to customers.
Vertical and Horizontal diode laser stacks and two-dimensional arrays, with power into the multi-kW range, for pumping, directed energy, hair removal, and materials processing.
Continuous Wave (CW) Stacks - microchannel cooling and uses it to enable optimum thermal management at high powers.
Pulsed Stacks - Covering QCW to long pulse conditions with conduction cooling and tap-water cooling options.
Broadest Wavelength Range - The range from 638 nm up to 2200 nm includes all major solid-state and fiber laser pump wavelengths as well as wavelengths used for defense, materials processing and medical aesthetics.
